1. Look at the valve lift AFTER 540 degrees.
2. after 540 degrees the piston is going UP, the air is leaking back out. residual air left is LESS. Less air to compress means lower pressure. easier to kick over.
3. Not rocket science.
4. close intake valve earlier and there will be more residual air to compress using kick lever, pressure is higher kick lever harder to push.
5. dynamics of cylinder charge change once engine is running and air column inertia prevents air escaping.
Thanks for the partial explanation.
I can’t graph it like you do. But my minds eye was telling me that a narrow footed BSA follower with a 7/8” radius is going to have different opening and closing times to a BSA follower with a 1 1/8” radius.
But I guess that if that’s not the case, I now know why the different radius made no noticeable difference to the kick start force required !
