Oil Filter Clearance

swooshdave

Joined

Apr 15, 2009

Messages

11,525

• Apr 22, 2010

• #1

I don't have the shocks installed (as in I don't have shocks yet to install) but I took an old oil filter and there sure wasn't much room for the swingarm to come down before it hit the filter. With the bike up on the center stand just how much clearance is there?



bmwbob

Joined

Dec 5, 2009

Messages

303

• Apr 22, 2010

• #2

On my 74 850 just enough clearance to get the retainer band on and that's a tight fit.



rx7171

Joined

Oct 8, 2007

Messages

656

• Apr 23, 2010

• #3

Dave:

You may have to drill the upper mounting hole further back.
This will rotate the filter down away from contact with the swingarm.
Don't ask why I know this :cry:

Bob



MarshalNorton

Joined

Jan 30, 2009

Messages

591

• Apr 23, 2010

• #4

SwooshDave,
my 72 combat has a factory installed filter and mount.
I use emgo filters in orange color w/o any clearance issues.
In fact I can get the filter wrench around the filter for removal.
I'd get the shocks on and get everything in rack before I get too concerned.
Are you using a larger car filter? ie.. maybe Fram?
Marshal



P

pete.v

Joined

Oct 31, 2009

Messages

5,193

• Apr 23, 2010

• #5

That filter seem kinda big. The NAPA PS7013 is perfect. Under 10bucks. This link will give the od. I would rather put on a nice filter that fits than drill another hole. What is the diameter of the one in place?
http://www.napafilters.com/filterlookup ... art=PS7013.

Full flow, low bypass, anti drainback and CHROME.



K

kraakevik

Joined

Oct 12, 2009

Messages

450

• Apr 23, 2010

• #6

Loosening the mounting bolts should allow you to reposition the filter assembly to give more clearance.



Tim Kraakevik
