I looked and didn't see this information posted so thought I would share. I have done some testing and discovered that you can scan the vehicle diagnostics using a standard automotive scan tool. So far I've used an inexpensive bluetooth scan tool to connect and it appears to work fine, I can see basic information like throttle position, temps, etc. I dont have a check engine light on so I don't know if we can clear codes but we can connect and read information. I have a more sophisticated SnapOn scan tool but I Haven't tested using it yet because i've loaned it out to a friend, once I get it back I will do some testing with it. This is good news for us owners that aren't close to a dealer.

I was very surprised to see Norton as using a standard 16 pin j1962 connector like a car, my other motorcycles use proprietary connectors for scanning and even when I jump the pins the protocol is proprietary. When I get a chance to do more testing I will update.

Just wanted to share, if you get a check engine light try an automotive scan tool to see if you can diagnose the problem, should be cheaper and easier than taking it to the dealer.

I've never personally used a scan tool. Don't you need a list of codes and translation of said problems?

Banditman said:
Just wanted to share, if you get a check engine light try an automotive scan tool to see if you can diagnose the problem, should be cheaper and easier than taking it to the dealer.
Click to expand...

Is the tool anything like the OBD 2 USB VAG COM cable that can be used for most fuel injected Triumphs (and others)? If so, how does one obtain the software?
It would extremely helpful to be able to apply new maps from your own computer.

I can now look at temps, rpm, throttle position, voltages, o2 sensors, anything the ECU sees! And of course see & reset trouble codes, I use my phone or any bluetooth device.Tthe transmitter was $8.00 on E-bay and the software was free!


Scan tool

BPHORSEGUY said:
I can now look at temps, rpm, throttle position, voltages, o2 sensors, anything the ECU sees! And of course see & reset trouble codes, I use my phone or any bluetooth device.Tthe transmitter was $8.00 on E-bay and the software was free!


Scan tool
Click to expand...

OK dude, you cannot show and describe something like this and not give full details LOL

G81 Can Cycle said:
BPHORSEGUY said:
I can now look at temps, rpm, throttle position, voltages, o2 sensors, anything the ECU sees! And of course see & reset trouble codes, I use my phone or any bluetooth device.Tthe transmitter was $8.00 on E-bay and the software was free!


Scan tool
Click to expand...

OK dude, you cannot show and describe something like this and not give full details LOL
Click to expand...

I followed the ops instructions, I bought the cheapo transmitter on E-bay for $8. It plugs into the unused port under the seat where they plug in for re-mapping! The software is a free app or you can buy a paid version. Search Torque OMBDII on Playstore and Youtube! Hey, I had to do my own detective work, the op was vague!!!! LOL

Is that better G81?

BPHORSEGUY said:
G81 Can Cycle said:
BPHORSEGUY said:
I can now look at temps, rpm, throttle position, voltages, o2 sensors, anything the ECU sees! And of course see & reset trouble codes, I use my phone or any bluetooth device.Tthe transmitter was $8.00 on E-bay and the software was free!


Scan tool
Click to expand...

OK dude, you cannot show and describe something like this and not give full details LOL
Click to expand...

I followed the ops instructions, I bought the cheapo transmitter on E-bay for $8. It plugs into the unused port under the seat where they plug in for re-mapping! The software is a free app or you can buy a paid version. The only disapointment for me was that it reads the o2 sensors as voltage, my guess is they are narrow band?

Is that better G81?
Click to expand...

Oops I guess I will have to read the entire thread from now on

BPHORSEGUY said:
G81 Can Cycle said:
BPHORSEGUY said:
I can now look at temps, rpm, throttle position, voltages, o2 sensors, anything the ECU sees! And of course see & reset trouble codes, I use my phone or any bluetooth device.Tthe transmitter was $8.00 on E-bay and the software was free!


Scan tool
Click to expand...

OK dude, you cannot show and describe something like this and not give full details LOL
Click to expand...

I followed the ops instructions, I bought the cheapo transmitter on E-bay for $8. It plugs into the unused port under the seat where they plug in for re-mapping! The software is a free app or you can buy a paid version. Search Torque OMBDII on Playstore and Youtube! Hey, I had to do my own detective work, the op was vague!!!! LOL

Is that better G81?
Click to expand...

This is awesome! Might be better than TuneECU.

BPHORSEGUY said:
G81 Can Cycle said:
BPHORSEGUY said:
I can now look at temps, rpm, throttle position, voltages, o2 sensors, anything the ECU sees! And of course see & reset trouble codes, I use my phone or any bluetooth device.Tthe transmitter was $8.00 on E-bay and the software was free!

OK dude, you cannot show and describe something like this and not give full details LOL
Click to expand...

I followed the ops instructions, I bought the cheapo transmitter on E-bay for $8. It plugs into the unused port under the seat where they plug in for re-mapping! The software is a free app or you can buy a paid version. Search Torque OMBDII on Playstore and Youtube! Hey, I had to do my own detective work, the op was vague!!!! LOL

Is that better G81?
Click to expand...
Click to expand...

Yes, that is much better, thanks. I am a lazy SOB and would rather somebody else does all the detective work That's why I like Richard 7 so much LOL Can I get you to order for me too. ROTFL

Have a good day, and thanks for your help,

This is very useful -- Thank you for sharing.

John, When ever I ride the 961 and follow a guy with a cigar I think of you now....

I got it working, but there is a whole lot more that it can do. pretty complicated set up need a template to see other ECU inputs thnx
