crank nose diameter

Onder

VIP MEMBER
Joined
May 11, 2010
Messages
4,091
Country flag
What is the diameter of the nose of the crank? 850 Commando that is.
OD of seal for same is 1"?

"Nose"

The vernacular...

In native tongue, is this self explanatory?

Is the PTO end of a crank shaft known as the "butt" or "tail"?

Seriously, trying to keep up... :)

TIA

"Nose"

The vernacular...

In native tongue, is this self explanatory?

Is the PTO end of a crank shaft known as the "butt" or "tail"?

Seriously, trying to keep up... :)

TIA
I've never heard it called anything other than the nose of the crank

IE


Attachments

  • crank nose diameter
    386.5 KB · Views: 66
Any chance somebody can give me a measurement. Prefer imperial but Ill take it in metric.

Any chance somebody can give me a measurement.

Correction. 9/16". (Camshaft is 5/8" (0.625").

Edit:
OD of seal for same is 1"?

The seal O/D is 1.1/16" (26.99mm).


"OD: 1+1/16" (27.1mm)
ID: 1/2" (13.2mm)
Width: 3/16" (4.4mm)"
